CCO/Hemo Configuration Continuous Cardiac Output (CCO) & Continuous Hemodynamics (Optional)

1 - 6 Addendum to V Series Operating Instructions

1.2.3 Alarm Responses: CCO/Hemo Tab

To display the alarm responses for the CCO/Hemo tab:

1. Select the Alarms tab from the Navigation Area.

2. Select the Responses button.

3. Select the CCO/Hemo tab.

TABLE 1-2 contains the alarm responses for the CCO/Hemo parameter.

1.2.4 Configuring the CCO Parameter

1. Select the Setup tab from the Navigation Area.

2. Select the Parameters button, then select the CCO button.

Select the CCO digital tile.

3. Select the Setup tab (as shown in FIGURE 1-4).

NOTE: The current parameter setting displays in bold to the right of each

button.

TABLE 1-2

ALARM LEVELS*

FACTORY

DEF

AULT ALARM RESPONSES

ALARM LEVELS

BUTTO

N HIGH MEDIUM LOW

PRINT ON

ALARM

SAVE TO

EVENT

NURSE

CALL

CCO/CCI X X X Off On Off

SVR/SVRI X X X Off On Off

RVEF/EDV/EDVI/SV/SVI — X X Off On Off

SvO2 X X X Off On Off

* X indicates available alarm level, — in

dic

ates alarm level not available

** The factory default configuration settings are in bold.
