V Series Operating Instructions 3 - 11

Display Setup Display Options Dialog

2. Select the Display button, then select the Display Setup button.

The Display Setup dialog displays (as shown in FIGURE 3-4).

FIGURE 3-4 Example Display Setup Dialog (Locked Presets)

3. Select the preset from the Display Presets list that requires locking/unlocking.

4. Select the Lock Unlock button.

The Create Password or Enter Password keyboard displays.

5. Enter a password, then select the Accept button.

• Locked presets display with a locked icon beside the preset name (as shown in FIGURE 3-

4).

• Unlocked presets display without the locked icon.

3.2.5 Temporarily Editing a Locked Display Preset

Temporary changes may be made to a locked preset. Changes remain active until any of the

following occur:

• Patient is discharged

•Device is restarted

• Original screen layout is restored

• Another preset is edited

To edit a locked preset:

• Select the Display Options icon located in the upper right corner of the Header Bar.

1. Select the Setup tab from the Navigation Area.

2. Select the Display button, then select the Display Setup button.

The Display Setup dialog displays (as shown in FIGURE 3-2).
