Digital Tiles Continuous Cardiac Output (CCO) & Continuous Hemodynamics (Optional)

1 - 14 Addendum to V Series Operating Instructions

1.4.11 Hemo Tile Setup

To configure the parameters that display in the Hemo tile:

1. Select the Hemo tile.

2. Select the Setup tab.

3. Select the Hemo Tile Setup button.

The Hemo Tile Setup dialog displays (as shown in FIGURE 1-10).

FIGURE 1-10

4. Navigate in this dialog by using the buttons described in TA

BLE 1-4.

TABLE 1-4

BUTTON DESCRIPTION

Add Adds the highlighted parameter(s) to the Sel

ected list (located on the

right side of the dialog).

NOTE: A maximum of six (6) parameters may be

highl

ghted in the list before selecting the

button.

Remove Removes the highlighted parameter(s) from the Sel

cted list and

moves them to the Choices list.

Remove All Removes all the selected parameters from the Sel

ected list and moves

them to the Choices list.

Move to Top Moves the selected parameter to the top position in the Sele

cted list.

Move Up Moves the selected parameter up one position in the Sel

ected list.

Move Down Moves a parameter from the Sele

cted list down one position.
