9 Visualization
Maschinenfabrik Reinhausen GmbH 2020 1054453918/14 EN ETOS
®
TD
Deleting a configuration
If necessary, you can delete the data point configuration. To do so, proceed
as follows:
1. Go to Settings > Mapping.
2. Select the desired function.
3. Press the Delete button to delete the configuration.
9.7.8 Configure data points (optional)
You can use the optional "Configure data points" function to adjust the con-
trol system data points of the device. You can only configure the data points
on a PC using the web-based visualization.
9.7.8.1 Configuring IEC 60870-5-101 data points
You can adjust the following data point properties for the IEC 60870-5-101
control system protocol:
Column Description Modifiable Setting range
Active You can use the checkbox to set whether the data point is
to be transferred via the control system protocol or not.
Yes Active/inactive
IOA Data point address. The setting range is based on the set-
ting for the "Octet number of information object address"
parameter (octet 2 or 3).
Yes Octet 2: 1...65,535
Octet 3:
1...16,777,215
Name Data point designation. No -
Type Data point type. No -
Group Data point group or groups. You must enter the group
membership as a binary code (5 bits). A maximum of 5
groups is possible. Example:
▪ 00000: belongs to no groups
▪ 00001: group 1
▪ 01000: group 4
▪ 01001: group 1 and group 4
Yes 00000...11111
INTG The value indicates whether the data point is to be in-
cluded in a general query (1) or not (0).
Yes 0, 1
