MR ETOS TD User Manual

9 Visualization
Maschinenfabrik Reinhausen GmbH 2020 2094453918/14 EN ETOS
®
TD
Behavior
You can use this parameter to set the behavior of the device when the event
message is issued. You can select the following options:
Setting Behavior
Off The limit value is not monitored.
Auto blocking Automatic regulation is blocked.
You can continue to perform tap-change operations in
manual mode.
Auto/manual blocking Automatic regulation is blocked.
You cannot perform tap-change operations in manual
mode.
Table73: Behavior when an event message is issued
Delay time
You can use this parameter to set the delay time in order to delay the issuing
of the event message.
9.22.9 Temperature monitoring
You can set different limit values for every measured/calculated temperature
. If the measured temperature is greater than limit value > or >>, the device
triggers an event message. If the measured temperature is less than limit
value < or <<, the device triggers an event message.
Settings
Parameters
Temperat...ing
<< < > >>
Hot-spot
Top oil
Ambient
Bottom oil
OLTC
GP 1
GP 2
GP 3
GP 4
- - 117.0°C 122.0°C
90.0°C 105.0°C-20.0°C-25.0°C
50.0°C 60.0°C-20.0°C-30.0°C
90.0°C 105.0°C-20.0°C-25.0°C
100.0°C 110.0°C-20.0°C-25.0°C
95.0°C 100.0°C-20.0°C-30.0°C
95.0°C 100.0°C-20.0°C-30.0°C
95.0°C 100.0°C-20.0°C-30.0°C
95.0°C 100.0°C-20.0°C-30.0°C
95.0°C100.0°C-20.0°C-30.0°C95.0°C100.0°C-20.0°C-30.0°C95.0°C100.0°C-20.0°C-30.0°C95.0°C100.0°C-20.0°C-30.0°C
Home
Events
Information
Recorder
Settings
EN
CHANGE
REBOOT
admin 04.02.2020 11:14
Figure141: Temperature monitoring
1. Go to Settings > Parameters > Temperature monitoring.
2. Select the desired parameter.
3. Set the desired parameter.
4. Press the Accept button to save the modified parameter.
