9 Visualization
Maschinenfabrik Reinhausen GmbH 2020 2134453918/14 EN ETOS
®
TD
9.23 Target-tap-position operation
When target-tap-position operation is activated, the device automatically
switches to this target tap position.
Figure146: Move to the defined target tap position
1. Go to Settings > Parameters > Grid > Move to the defined target tap
position.
2. Select the desired parameter.
3. Set the desired parameter.
4. Press the Accept button to save the modified parameter.
Target tap position
You can use this parameter to define a target tap position.
9.24 Measured values
You can display the measured values for the device.
9.24.1 Displaying current measured values
The current measured values can be displayed on the measured value
screen. Note that the displayed measured values may differ from the raw
values displayed in the information display of the UI assembly. The mea-
sured values are prepared for the measured value display by the device as
follows:
▪ The tap-change operation set for the current transformer and voltage
transformer is taken into account, as is a corresponding phase displace-
ment.
▪ The UI assemblies use the generator sign convention. The device dis-
plays the measured values using the load sign convention.
