4.5.3 Control cabinet
The control cabinet contains the following components:
Figure6: Control cabinet
1 Tap position display 2 Control switch
3 Ethernet interface ETH1.1 (RJ45) 4 Plug socket X19, max. 10A
5 Motor protective switch Q1 6 Fuses F14 and F25
