MR ETOS TD User Manual

6 Mounting
Maschinenfabrik Reinhausen GmbH 2020 554453918/14 EN ETOS
®
TD
6.2 Cable recommendation
Please note the following Maschinenfabrik Reinhausen GmbH recommenda-
tion when wiring the device.
▪ Excessive line capacitance can prevent the relay contacts from interrupt-
ing the contact current. In control circuits operated with alternating current,
take into account the effect of the line capacitance of long control cables
on the function of the relay contacts.
▪ If you want to route Ethernet connections from a control cabinet or build-
ing, we recommend using fiber-optic cables (in accordance with the
IEC61850-90-4 recommendation).
▪ Ensure that the copper cables used have a temperature resistance of
70°C.
Cable Assembly Type Cross section Material Max. length
Power supply X1 Unshielded 2.5mm² Copper -
Voltage measurement X10 (UI1/3) Shielded 2.5mm² Copper -
Current measurement X10 (UI1/3) Unshielded 4mm² Copper -
Digital signal inputs DIO28-15,
DIO42-20
Shielded 1.5mm
2
Copper 400m (<25Ω/km)
Digital signal outputs* DIO28-15,
DIO42-20
Shielded 1.5mm
2
Copper -
Analog signal inputs X6 (AIO 2/4) Shielded 1mm
2
Copper 400m (<25Ω/km)
Analog signal outputs X6 (AIO 2/4) Shielded 1mm
2
Copper -
RS232, SUB-D CPUI Shielded 0.25mm
2
- 25m
RS485, SUB-D CPUI Shielded 0.25mm
2
- 140m
CAN bus CPUI Shielded 0.75mm² - 2000m (entire
CAN bus)
Ethernet RJ45 CPUI Min. CAT5,
shielded S/FTP
- - 100m
Ethernet FO MC2-2, SW3-3 Duplex LC,
1310nm
- 2000m
Grounding connection Housing Unshielded 16mm² Copper -
Table14: Recommendation for connection cables
*) Observe line capacitance, see note above.
6.3 Information about connecting serial interfaces RS232 and
RS485
NOTICE
Damage to the device!
Using the wrong data cable may damage the device.
► Only use data cables which comply with the description below.
