4
Functions of the NT31/NT31C
Section 1-2
1-2 Functions of the NT31/NT31C
The NT31/NT31C has the following features.
1-2 -1 Features
Downsized Body
S Slim body (50 mm or less in the panel*).
S The communication cable connectors are housed in the unit so that they do not
protrude from the unit.
* When mounted in a panel of the recommended thickness (page 38).
Construction Best Suited to the FA Environment
S The panel is an STN monochrome LCD type with backlight for the NT31 and an
STN color LCD type with backlight for the NT31C.
S The backlight unit and battery can be replaced at the operation site.
S Waterproofed equivalent to the NEMA4 standard and to IP65F*.
* The panel may not be usable in environments where it is exposed to oil for long
periods.
POWER
RUN
320 dots
240 dots
Wide angle of visibility
Touch Switch Operation
S Contrast and brightness are adjustable by touch switch operations.
Compatibility with Other PTs
S There is upward compatibility between the NT31/NT31C and the following mod-
els for screendata anduser programs: NT11S, NT20S, NT30, NT30C, NT600S,
NT610G, NT610C, NT620S, NT620C, NT625C, NT631, NT631. (After being
read to the Support Tool, screens must be modified in accordance with the
screen size. Depending on the function used, partial modification of programs
may also be necessary. For details, refer to APPENDIX I “Compatibility with
Screen Data of Other PT Models” (page 667) and the Support Tool manual.)
S The dimensions of the panel cut-out to accommodate the NT31/NT31C are the
same as for the NT30/NT30C.
Two Ports Featured as Standard: Port A for Common Use by Support Tool/Host and Port B for Exclusive
Use by the Host
S Communication with the host is possible via another port while connected to the
Support Tool.
S Reading bar code data from a bar code reader is possible via another port while
communicating with the host.
To Next Page
