243
Programming Console Function
Section 6-12
6-12-1 Usable Systems
The programming console function can be used with an NT31/NT31C connected
to a PC when using the communication method indicated below.
Communication
Method
Communication
Type
Applicable PCs Connected Port
NT Link (1:1)
C200HE-CPU42-(Z)E
(*1)
C200HG-CPU43-(Z)E
(*1)
C200HG-CPU63-(Z)E
(*1)
C200HX-CPU44-(Z)E
(*1)
C200HX-CPU64-(Z)E
(*1)
C200HX-CPU65-ZE
(*1)
C200HX-CPU85-ZE
(*1)
CQM1-CPU4j-EV1
(*1)
SRM1-C02-V1
CPU built-in RS-232C
port
RS-232C
CPM1-10CDR-j
CPM1-20CDR-j
CPM1-30CDR-j
CPM1A-10CDj-j
CPM1A-20CDj-j
CPM1A-30CDj-j
CPM1A-40CDj-j
Peripheral port
(*2)
NT Link (1:N)
CS1G-CPU42-E
(*1)
CS1G-CPU43-E
(*1)
CS1G-CPU44-E
(*1)
CS1G-CPU45-E
(*1)
CS1H-CPU63-E
(*1)
CS1H-CPU64-E
(*1)
CS1H-CPU65-E
(*1)
CS1H-CPU66-E
(*1)
CS1H-CPU67-E
(*1)
S CPU built-in
RS-232C port
S Peripheral port
(*3)
*1 The peripheral port programming console always has priority. If a programming
console is connected later, the programming console function of the NT31/NT31C is
invalidated and operation from the NT31/NT31C becomes impossible.
*2 An RS-232C cable cannot be connected to the peripheral port. An RS-232C adapter
(CPM1-CIF01) is required.
*3 The RS-232C cable cannot be directly connected to the peripheral port. An RS-232C
converting cable (CS1W-CN118) is required.
Reference: Note that the programming console function cannot be used with CPM1, CQM1,
and C200HX/HG/HE PCs of the following lot numbers.
CPM1: jjj5, jj*6
where * is a number in the range 1 to 9 or the letter X or Y.
CQM1: jjj3, jjj4, jjj5, jj*6
where * is a number in the range 1 to 9 or the letter X or Y.
C200HX/HG/HE: jjj5 jj*6
where * is a number in the range 1 to 9 or the letter X or Y.
