System Menu Operation Flow
Section 6-1
6-1 System Menu Operation Flow
Follow the procedure below when using the NT31/NT31C for the first time or
changing the system program.
[Create the Screen Data]
Create the data to be displayed on the NT31/NT31C by using the Support Tool.
For details on creating screen data, refer to the NT-series Support Tool Ver. 3.0 for
Windows95 Operation Manual (V053-E1-j).
[Start Up the NT31/NT31C (Display the System Menu)] (page 151)
Turn ON the power to the NT31/NT31C.
If no screen data has been registered, an error message is displayed. In this case,
press the “OK” touch switch on the error message screen to display the System
Menu.
If screen data has been registered and the RUN mode is established, perform the
appropriate operations on the touch panel to display the System Menu.
[Initialize the Memory] (page 157)
If necessary, initialize the memory of the NT31/NT31C by operation from the Sys-
tem Menu.
[Transmit the Screen Data] (page 171)
Connect the Support Tool to the NT31/NT31C and transmit the screen data from
the Support Tool to the NT31/NT31C.
For details on connecting the Support Tool, refer to 3-2 “Connecting to the Support
Tool” (page 41).
[Set the Memory Switches] (pages 174, 189)
Select the System Menu and set the operations of the NT31/NT31C — for exam-
ple the conditions for communication with the host — using the memory switches.
[Start Operation] (page 187)
Connect the NT31/NT31C to the host and start operation.
[System Maintenance] (page 212)
If an error occurs during operation, check the I/Os, settings, etc., by referring to
this guide.
