Before Operating
Section 1-5
1-6 Before Operating
Follow the procedure given below to start the system of the NT31/NT31C.
For the host link, refer to
pages 67 and 114, and the
manuals for the host link unit
and peripheral tools.
For the NT link (1:1), refer to
pages 81 and 127.
For the NT link (1:N), refer to
pages 84 and 130.
For the Memory link, refer to
pages 84 and 132
Host
Set the host settings.
Connect to the
NT31/NT31C.
Create the host program.
Start operation.
NT31/NT31C
Install the PT in the
operation panel.
(page 38)
Connect the power supply.
(page 39)
Install the system program.
*1
(refer to page 167 and the
Support Tool manual)
Make the settings in the
system installer mode.
*2
(page 166)
Transmit the screen data.
(page 171)
Set the memory switches.
(page 174)
Connect to the host.
When RS
-
232C used at the PT: refer to Section 4
When RS
-
422A/485 used at the PT: refer to Section 5
Confirm the settings and
check communication.
Support Tool
Install the Support Tool
at the computer.
(refer to the manual for
the Support Tool)
Create the screens.
(refer to Sections 7
through 9 and the
Support Tool manual)
*1 System program installation is only done in special circumstances, for example when
changing the system program, or to recover the original status of the installed
program. This operation is not normally necessary. When using other PC models
(sequencers), however, it is necessary to install specific system programs.
*2 Display of the system menu, and all change operations, can be inhibited. This
enables you to prevent the accidental deletion or alteration of screens and settings.
Reference
- For the system program, use the NT31/NT31C system program supplied as an
accessory with the NT series Support Tool (NT--ZJ3MX1/ZJCMX1--EV3).
- For the Support Tool,use NT--series Support Tool for Windows 95/98 (Ver.3.0.).
