467
Screen Creation Procedure
Section 8-1
8-1 Screen Creation Procedure
Follow the procedure shown below to create screens for the NT31/NT31C.
The following gives the procedure assuming that the setting for the NT31/NT31C
has been completed. The operating procedure for a Support Tool is not given
here. For the operating procedure for the Support Tool, refer to the NT-series Sup-
port Tool Ver. 3.0 for Windows95 Operation Manual (V053-E1-j).
Designate a work file.
[Creating a New Screen]
Tool Setting (for PT Type)
Set “NT31” for creating a screen for NT31,
and “NT31C” for NT31C.
System Setting (Memory Switch Setting)
Set the memory switches that determine the
basic operation of the NT31/NT31C.
The numeral/character string/bit memory table
settings should also be made at this stage.
Setting for PT Status Control/Notify Area
Allocate the PT status control area and PT
status notify area, necessary for the direct
connection function, to words at the host.
For details, refer to 7-2 “Areas for
Control/Notification” (page 265).
[Correcting an Existing File]
File Designation
[Importing DOS Version Data]
File Designation
Designate the work file to be data converted.
NT-series Support Tool
NT-series Support Tool
Reference: If is not necessary to allocate words to window control area, when the window is
not used or when the window is not controlled from the host.
To Next Page
