Ricoh Aficio SP C811DN User Manual

Using the SmartDeviceMonitor Port
Installing DeskTopBinder-SmartDeviceMonitor for Client
• To install SmartDeviceMonitor for Client under Windows 2000/XP Professional, Windows Server
2003, and Windows NT 4.0, you must have an account that has Manage Printers permission. Log
on as an Administrator.
• Install SmartDeviceMonitor for Client before installing the printer driver when using the SmartDevice-
Monitor for Client port.
1. Quit all applications currently running.
2. Insert the CD-ROM into the CD-ROM drive.
The installer starts.
3. Select an interface language, and then click [OK].
The default interface language is English.
4. Click [DeskTopBinder-SmartDeviceMonitor for Client].
5. Select an interface language, and then click [Next>].
The default interface language is English.
6. The message to quit all other applications appears. Quit all applications, and then click [Next
>].
7. Click [Yes]
8. The DeskTopBinder Lite Setup dialog appears, and then click [Next >].
9. The software license agreement appears in the [License Agreement] dialog box. After read-
ing through its contents, click [Yes].
10. Click [Full install] or [Custom Install].
[Full install] installs all required applications: DeskTopBinder Lite and SmartDeviceMonitor for Client.
[Custom Install] installs selected applications.
11. Follow the instructions on the display and click [Next >] to proceed next step.
12. After the installation is completed, select one of the options to restart the computer either
now or later, and click [Complete].
Restart the computer to complete installation.
• Auto Run may not work with certain operating system settings. If this happens, launch "Setup.exe" on
the CD-ROM root directory.
Using the SmartDeviceMonitor Port
23
1

Ricoh Aficio SP C811DN Specifications

General

Brand	Ricoh
Model	Aficio SP C811DN
Category	Printer
Language	English
