Ricoh Aficio SP C811DN User Manual

Changing the Port Settings for SmartDeviceMonitor for Client
Follow the procedure below to change the SmartDeviceMonitor for Client settings, such as TCP/IP timeout,
recovery/parallel printing, and printer groups.
Windows 95/98:
1. Open [Printers] window from [Start] menu.
2. In the [Printers] window, click the icon of the printer you want to use. On the [File] menu,
click [Properties].
3. Click the [Details] tab, and then click [Port Settings...].
The [Port Settings] dialog box appears.
Windows 2000/Windows NT 4.0:
1. Open [Printers] window from [Start] menu.
2. In the [Printers] window, click the icon of the printer you want to use. On the [File] menu,
click [Properties].
3. On the [Ports] tab, click [Configure Port...].
The [Port Configuration] dialog box appears.
Windows XP, Windows Server 2003:
1. Open the [Printers and Faxes] window from the [Start] menu.
The [Printers and Faxes] window appears.
2. Click the icon of the printer you want to use. On the [File] menu, click [Properties]. The printer
properties appear.
3. Click the [Ports] tab, and then click [Configure Port...].
The [Port Configuration] dialog box appears.
• For TCP/IP, timeout setting can be configured.
• User, proxy, and timeout settings can be configured for IPP.
• If no settings on the [Recovery/Parallel Printing] tab are available, follow the procedure below.
1. Click [Cancel] to close the [Port Configuration:] dialog box.
2. Start SmartDeviceMonitor for Client, and then right-click the SmartDeviceMonitor for Client icon
on the tasktray.
Using the SmartDeviceMonitor Port
35
