15. Click [Manual load] in the [Communication type] area, and then click [OK]. Check the set-
tings, and then click [OK].
16. Set up the network connection to a print server. Select a context specified using NIB Setup
Tool, and then click [Create] on the [Object] menu.
17. In the [Class of new object] box, click [Print Server], and then click [OK]. For NetWare 5,
click [Print Sever (Non NDPS)].
18. In the [Print Server Name] box, enter the print server name.
Use the same print server name specified using NIB Setup Tool.
19. Select the [Define additional properties] check box, and then click [Create].
20. Assign the printer to the created print server. Click [Assignments], and then click Add in the
[Assignments] area.
21. In the [Available objects] box, click the queue you created, and then click [OK].
22. In the [Printers] area, click the printer you assigned, and then click [Printer] [Number].
23. Enter the printer number, and then click [OK]. Check the settings, and then click [OK].
24. Start the print server by entering the following from the console of the NetWare server.
If the print server is in operation, quit and restart it.
To exit
CAREE: unload pserver
To start
CAREE: load pserver "print_server_name"
25. Enter the printer server name as the context name, and then press the [OK] key.
26. Select the printer name on the context menu, and then press the [OK] key.
Setting up using Web Image Monitor
1. Start Web Image Monitor.
2. Click [Login].
A dialog box for entering the login user name and login password appears.
3. Enter the login user name and password, and then click [Login].
For details about the login name and password, consult your administrator.
4. Click [Configuration] in the left area, and then click [NetWare Print Settings].
5. Confirm the settings, and then click [OK].
Configuration is now complete. Wait several minutes before restarting Web Image Monitor.
6. Click [Logout].
Using NetWare
301
