Component Definition and Maintenance Chapter 5
Table 27 - Status of U6 Display
External Input/Output Board Replacement
To replace the External Input/Output Boards:
1. Ensure that all medium voltage and control voltage power to the drive is
isolated and locked out.
2. Note and Mark the location and orientation of all the plugs, cables, and
connectors into the XIO board. Use the electrical drawing as a reference.
3. Using your static strap, disconnect all of the connections.
4. Remove the XIO board assembly from the low voltage control cabinet.
The XIO board mounts on a DIN rail, so a special 3-piece assembly is used
to secure the board. The assembly does not come with the new board, so
the old board needs to be removed from the assembly and the new board
installed in its place.
5. Install the new XIO board assembly in the low voltage control cabinet.
6. Reconnect all connections and verify the locations.
7. Apply Low Voltage power and complete a System Test and Medium
Voltage tests to ensure the new board functions properly.
LED Status Description
Solid Red Board Failure
Alternate Flashing of Red and Green No Communication Available to ACB board (Normal at
Power on, during firmware download and with
unprogrammed drive)
Display Description Explanation
— No valid address found – More than 6 XIO cards on network
– IO cable failure
– IO card failure
– CB failure
0 Card in “Master” mode – Rockwell Use Only
– Remove connection to J3 and recycle power
1 – 6 Valid address – Normal
Decimal point ON Indicates network activity – Normal
Decimal point OFF No activity on the network – Normal at Power on, during firmware download
and with unprogrammed drive
