A-6 Specifications
Bulletin 284G
Electrical Ratings UL/NEMA IEC
Power Circuit
Rated Operation Voltage 380/220V…480.277V AC 380/220V…480.277V AC
Rate Insulation Voltage 600V 600 V
Rated Impulsed Voltage 4 kV 4 kV
Dielectric Withstand 2200V AC 2500V AC
Operating Frequency 50/60 Hz 50/60 Hz
Utilization Category N/A AC-3
Protection Against Shock N/A IP2X
Rated Operating Current Max.
2.5 A
5.5 A
16 A
Short Circuit
Protection
SCPD Performance
Current Rating Voltage 480Y/277V
—10 A
Sym. Amps RMS
65 kA
25 A 30 kA
SCPD Fuses,
only fuse types: J, CC, and T
100 A maximum
SCPD UL 489 Circuit Breakers 100 A maximum
Safety Products Only
C10 Base: 100 A maximum
C25 Base: 60 A maximum
SCPD List Size per NEC Group Motor —
Control
Circuit
Rated Operation Voltage
Safety Products only: 24V DC (+10%, -15%) A2 (should be grounded at voltage source)
120V AC (+10%, -15%) A2 (should be grounded at voltage source)
Rated Short Circuit 1 kA
SCPD 10 A circuit breaker or equivalent
Rate Insulation Voltage 250V 250V
Rated Impulsed Voltage — 4 kV
Dielectric Withstand 1500V AC 2000V AC
Overvoltage Category — III
Operating Frequency 50/60 Hz 50/60 Hz
Power Requirements
Units Non-Safety Products Safety Products
Control Voltage Volts 120V AC 24V DC
Contactor (Pick Up) Amps 0.35 plus motor brake pick-up current 0.63
Contactor (Hold In) Amps 0.10 plus motor brake hold-in current 0.63
120V AC Brake (Pick Up) Amps — 0.29 plus motor brake pick-up current
120V AC Brake (Hold In) Amps — 0.04 plus motor brake hold-in current
Total Control (Pick Up) VA (W) 42 (15)
Total Control (Hold In) VA (W) 12 (15)
Input Ratings
Rated Operation Voltage 24V DC
Input On-State Voltage Range 10…26V DC
Input On-state Current
3.0 mA @ 10V DC
7.2 mA @ 24V DC
Input Off-state Voltage Range 0…5V DC
Input Off-state Current <1.5 mA
Input Filter — Software Selectable
Off to On Settable from 0…64 ms in 1 ms increments
On to Off Settable from 0…64 ms in 1 ms increments
Input Compatibility N/A IEC 1+
Number of inputs 6
Sensor Source
Voltage Status Only 11…25V DC from DeviceNet™
Current Available 50 mA MAX per Input, 300 mA Total
