4-18 Bulletin 284G Programmable Parameters for Sensorless Vector Controllers
Drive DeviceNet Group
Drive Control
This parameter provides the status of drive parameters.
Parameter Number 48
Access Rule GET
Data Type WORD
Group Drive DeviceNet
Units —
Minimum Value 0
Maximum Value 4095
Default Value 0
Bit
Function
11109876543210
——————————— X Accel 1 En
—————————— X — Accel 2 En
————————— X —— Decel 1 En
———————— X ——— Decel 3 En
——————— X ———— Freq Sel 0
—————— X ————— Freq Sel 1
————— X —————— Freq Sel 2
———— X ——————— Reserved
——— X ———————— Drv In 1
—— X ————————— Drv In 2
— X —————————— Drv In 3
X ——————————— Drv In 4
Drvin PrFltState
This parameter, in conjunction with Parameter 50, defines how the Drive Digital
Inputs 1…4 will respond when a protection trip occurs. When set to 1, Drive Digital
Inputs 1…4 continue to operate as command via the network. When set to 0, Drive
Digital Inputs 1…4 will open or close as determined by setting in Parameter 50.
0 = Go to PrFlt Value
1 = Ignore PrFlt
Parameter Number 49
Access Rule GET/SET
Data Type BOOL
Group Drive DeviceNet
Units —
Minimum Value 0
Maximum Value 1
Default Value 0
Drvin PrFltValue
This parameter determines the state of Drive Digital Inputs 1…4, assumes when a
trip occurs and Parameter 49 is set to 0.
0 = Open
1 = Close
Parameter Number 50
Access Rule GET/SET
Data Type BOOL
Group Drive DeviceNet
Units —
Minimum Value 0
Maximum Value 1
Default Value 0
