B-2 Bulletin 280G/281G CIP Information
DOL Reversing Type Product Codes
and Name String
The following table lists the product codes for the Bulletin 281G
Distributed Motor Controllers:
Table B.3 Bul. 281G Distributed Motor Controller Product Codes and Name
Strings
Table B.4 Bul. 281G Distributed Motor Controller Safety Product Codes and
Name Strings
➊ 22= Motor Starter
DeviceNet Objects The ArmorStart Distributed Motor Controller supports the following
DeviceNet object classes:
Table B.5 DeviceNet Object Classes
281G
Device Type
➊
Product
Code
Contactor
Size Code
Overload
Current Rating
Control Power
Voltage
22 0x4C4 100C-12 0.5…2.5 A 120V AC
22 0x4C5 100C-12 1.1…5.5 A 120V AC
22 0x4C6 100C-23 3.2…16 A 120V AC
281G
Device Type
➊
Product
Code
Contactor
Size Code
Overload
Current Rating
Control Power
Voltage
22 0x4Ee1 100C-12 0.5…2.5 A 24V DC
22 0x4E2 100C-12 1.1…5.5 A 24V DC
22 0x4E3 100C-23 3.2…16 A 24V DC
Class Object
0x0001 Identity
0x0002 Message Router
0x0003 DeviceNet
0x0004 Assembly
0x0005 Connection
0x0008 Discrete Input Point
0x0009 Discrete Output Point
0x000F Parameter Object
0x0010 Parameter Group Object
0x001D Discrete Input Group
0x001E Discrete Output Group
0x0029 Control Supervisor
0x002B Acknowledge Handler
0x002C Overload Object
0x00B4 DN Interface Object
