Bulletin 280G/281G CIP Information B-21
Discrete Output Group Object —
CLASS CODE 0x001E
No class attributes are supported for the Discrete Output Group
Object.
A single instance of the Discrete Output Group Object is supported. It
contains the following attributes:
Table B.50 Discrete Output Instance Attributes
The following common services are implemented for the Discrete
Output Group Object:
Table B.51 Discrete Output Group Common Services
Attribute ID Access Rule Name Data Type Value
3 Get Number of Instances USINT 4 for DOL
4 Get Binding Array of UINT List of DOP instances; 1, 2, 3, 4
6 Get/Set Command BOOL 0=idle; 1=run
104 Get/Set Network Status Override BOOL
0=No Override (go to safe state)
1=Override (run local logic)
105 Get/Set Comm Status Override BOOL
0=No override (go to safe state)
1=Override (run local logic)
Service Code
Implemented for:
Service Name
Class Instance
0x0E No Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
