C-6 Bulletin 284G CIP Information
Custom Parameter Based Word-
Wise I/O Assembly
Table C.13 CustomParameter Based Word Wise (Produced) Assembly
Instance
Word-Wise Bit-Packed Assemblies Assemblies whose instance numbers are 180...189 are all one word
(16 bits) long. They can be used stand-alone, but their main use is to
assemble information for EDS file parameters. These Word-Wise
assemblies become the building blocks for the Custom Parameter
Based Word-Wise assembly described in Table C.13.
Table C.14 Instance 181 — Hardware Inputs 1…16
Table C.15 Instance 182 — Consumed Network Inputs 1…16
Table C.16 Instance 183 — Produced Network Outputs 1…15
Instance 120
Word Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0
0 Value of the parameter pointed to by Produced Word 0 Param (low byte)
1 Value of the parameter pointed to by Produced Word 0 Param (high byte)
1
2 Value of the parameter pointed to by Produced Word 1 Param (low byte)
3 Value of the parameter pointed to by Produced Word 1 Param (high byte)
2
4 Value of the parameter pointed to by Produced Word 2 Param (low byte)
5 Value of the parameter pointed to by Produced Word 2 Param (high byte)
3
6 Value of the parameter pointed to by Produced Word 3 Param (low byte)
7 Value of the parameter pointed to by Produced Word 3 Param (high byte)
Instance 181 — This is a Read Only Status Assembly
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 — — Input 5 Input 4 Input 3 Input 2 Input 1 Input 0
1 — — — — — — — —
Instance 182 — This is a Read/Write Control Assembly
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0
Net Input
8
Net Input
7
Net Input
6
Net Input
5
Net Input
4
Net Input
3
Net Input
2
Net Input
1
1
Net Input
16
Net Input
15
Net Input
14
Net Input
13
Net Input
12
Net Input
11
Net Input
10
Net Input
9
Instance 183 — This is a Read Only Status Assembly
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Net Out 8
Net Out
7
Net Out
6
Net Out
5
Net Out
4
Net Out
3
Net Out
8
Net Out
1
1 Reserved
Net Out
15
Net Out
14
Net Out
13
Net Out
12
Net Out
11
Net Out
10
Net Out
9
