C-30 Bulletin 284G CIP Information
DeviceNet Interface Object —
CLASS CODE 0x00B4
This vendor specific object has no class attributes.
A single instance (Instance 1) of the DeviceNet Interface Object is
supported
Table C.63 DeviceNet Interface Object Instance Attribute:
The following common services are implemented for the DeviceNet
Interface Object
Table C.64 DeviceNet Interface Object Common Services:
Attribute ID
Access
Rule
Name Data Type Min./Max. Default Description
7 Get/Set Prod Assy Word 0 USINT 1 Defines Word 0 of Assy 120
8 Get/Set Prod Assy Word 1 USINT 5 Defines Word 1 of Assy 120
9 Get/Set Prod Assy Word 2 USINT 6 Defines Word 2 of Assy 120
10 Get/Set Prod Assy Word 3 USINT 7 Defines Word 3 of Assy 120
13 Get/Set Starter COS Mask WORD 0 — 0xFFFF 0xFFFF Change of state mask for starter bits
15 Get/Set Autobaud Enable BOOL 0 — 1 1 1 = enabled; 0 = disabled
16 Get/Set
Consumed Assy
USINT 0…185
160
(drive 164)
3, 160, 162, 164, 166, 170, 182, 187, 188
17 Get/Set
Produced Assy
USINT 100…187
161
(drive 165)
52, 120, 161, 163, 165, 167, 171,
181…190
19 Get/Set Set To Defaults BOOL 0…1 0 0 = No action; 1 = Reset
23 Get I/O Produced Size 0…8
24 Get I/O Consumed Size USINT 0…8
30 Get DNet Voltage UINT DeviceNet Voltage
50 Get/Set PNB COS Mask WORD 0…0x00FF 0 Change of state mask for PNBs
64 Get/Set Unlock Identity Instances USINT 0 Unlock when set to 99 hex
Service
Code
Implemented for
Service
Name
Class Instance
0x0E No Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
