Bulletin 284G CIP Information C-5
Assembly Object — CLASS CODE
0x0004
The following class attributes are supported for the Assembly Object
Table C.11 DeviceNet Assembly Object:
All of the various instances of the assembly object will support
Attribute 3. Table C.12 summarizes the various instances that are
supported
Table C.12 DeviceNet Assembly Object Instance Attributes:
Attribute ID Access Rule Name Data Type Value
2 Get Max Instance UINT 190
Attribute
ID
Type Description
3 Consumed Required ODVA Consumed Instance
52 Produced Required ODVA Produced Instance
120 Produced Custom Parameter Based Word Wise Assembly
160 Consumed Default Consumed Instance for DOL and SoftStart units
161 Produced Default Produced Instance for DOL and SoftStart units
162 Consumed
Standard Consumed Instance for DOL and SoftStart with Network
Inputs
163 Produced
Standard Produced Instance for DOL and SoftStart with Network
Outputs
164 Consumed Default Consumed Instance for Inverter type units
165 Produced Default Produced Instance for Inverter type units
166 Consumed
Standard Consumed Instance for Inverter type units with Network
Inputs
167 Produced
Standard Produced Instance for Inverter type units with Network
Outputs
170 Consumed Power Flex Native Format Consumed Instance
171 Produced Power Flex Native Format Produced Instance
181 Produced User Inputs
182 Consumed Consumed Network Bits (a.k.a Network Inputs)
183 Produced Produced Network Bits (a.k.a. Network Outputs)
184 Produced Trip Status Bits
185 Produced Starter Status Bits
186 Produced DeviceNet Status Bits
187 Consumed Starter Control Bits
188 Consumed Drive Control Bits
189 Produced Warning Status Bits
190 Produced 1799 - ZCIO Bits
