B-8 Bulletin 280G/281G CIP Information
Table B.24 Instance 160 is the default output (consumed) assembly for
Standard Distributed Motor Controllers
Table B.25 Instance 162 is the standard output (consumed) assembly with
Network Inputs
Standard Distributed Motor Controller Input (Produced)
Assemblies
Table B.26 Instance 52 is the required input (produced) assembly defined in
the DeviceNet Motor Starter Profile
Table B.27 Instance 161 is the default input (produced) assembly for
Standard Distributed Motor Controllers
Instance 160 — Default Consumed Standard Distributed Motor Controller
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Reserved Reserved — — —
Fault
Reset
Run Rev Run Fwd
Instance 162 — Standard Consumed Starter with Network Inputs
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Reserved Reserved — — —
Fault
Reset
Run Rev Run Fwd
1 Net In 8 Net In 7 Net In 6 Net In 5 Net In 4 Net In 3 Net In 2 Net In 1
2 Net In 16 Net In 15 Net In 14 Net In 13 Net In 12 Net In 11 Net In 10 Net In 9
Instance 52 — ODVA Starter
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
— — — — — — Running — Fault
Instance 161 — Default Producted Standard Distributed Motor Controller
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Reserved 140M On Reserved Ready
Running
Rev
Running
Fwd
Warning Tripped
1 Reserved Reserved User In 5 User In 4 User In 3 User In 2 User In 1 User In 0
