Rockwell Automation ArmorStart Bulletin 280G User Manual

Bulletin 284G CIP Information C-13
Connection Object — CLASS CODE
0x0005
No class attributes are supported for the Connection Object.
Multiple instances of the Connection Object are supported, Instances
1, 2, and 4 from the Group 2 predefined master/slave connection set,
Instances 5 and 6 are available through explicit UCMM connections.
Instance 1 is the Predefined Group 2 Connection Set Explicit
Message Connection. The following Instance 1 attributes is supported
Table C.35 Connection Object Instance 1 Attributes:
Attribute
ID
Access
Rule
Name
Data
Type
Value
1 Get
State
USINT
0 = non-existent
1 = configuring
3 = established
4 = timed out
2 Get Instance Type USINT 0 = Explicit Message
3 Get
Transport Class Trigger
USINT
0x83 — Server, Transport
Class 3
4 Get
Produced Connection ID
UINT
10xxxxxx011
xxxxxx = node address
5 Get
Consumed Connection ID
UINT
10xxxxxx100
xxxxxx = node address
6 Get Initial Comm Characteristics USINT 0x22
7 Get Produced Connection Size UINT 0x61
8 Get Consumed Connection Size UINT 0x61
9 Get/Set Expected Packet Rate UINT in milliseconds
12 Get
Watchdog Action
USINT
01 = auto delete
03 = deferred delete
13 Get
Produced Connection Path
Length
UINT
0
14 Get Produced Connection Path Empty
15 Get
Consumed Connection Path
Length
UINT
0
16 Get Consumed Connection Path Empty
