C-8 Bulletin 284G CIP Information
Table C.21 Instance 190 is the 1999-ZCIO Native Format Produced Assembly
Standard Distributed Motor
Controller I/O Assemblies
Standard Distributed Motor Controller I/O Assemblies are available
on all Starter Types.
Standard Distributed Motor Controller Output (Consumed)
Assemblies
Instance 3 is the required output (consumed) assembly defined in the
DeviceNet Motor Starter Profile.
Table C.22 ODVA Starter
Instance 160 is the default output (consumed) assembly for Bulletin
280G/281G Distributed Motor Controllers
Table C.23 Instance 160 — Default Consumed Standard Distributed Motor
Controller.
Instance 162 is the standard output (consumed) assembly with
Network Inputs for Bulletin 280G/281G Distributed Motor
Controllers
Table C.24 Standard Consumed Starter with Network Inputs.
Instance 190 1799-ZCIO Native Format Produced Assembly
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0
Running
Rev
Running
Fwd
Warning Tripped Input 3 Input 2 Input 1 Input 0
1 Reserved
Logic
Enable
Reserved 140M On HOA
2 Drive In 4 Drive In 3 Drive In 2
Drive In
1
Reserved Reserved Run Rev
Run
Fwd
3 Reserved Jog Rev Jog Fwd
4 Net Out 8 Net Out 7 Net Out 6
Net Out
5
Net Out 4 Net Out 3 Net Out 2
Net Out
1
5 ZIP CCV (Low)
6 ZIP CCV (High)
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 — — — — — — — Run Fwd
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Reserved Reserved
Fault
Reset
Run Rev Run Fwd
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Reserved Reserved
Fault
Reset
Run Rev Run Fwd
1 Net In 8 Net In 7 Net In 6 Net In 5 Net In 4 Net In 3 Net In 2 Net In 1
2 Net In 16 Net In 15 Net In 14 Net In 13 Net In 12 Net In 11 Net In 10 Net In 9
