Bulletin 284G CIP Information C-11
Instance 167 is input (produced) assembly for Inverter Type
Distributed Motor Controllers with Network Outputs
Table C.31 Instance 167 —Produced Inverter Type Starter with Network
➊ Refers to control brake contactor status.
Power Flex Native Assemblies
These assembly instances have the same data format as the Power
Flex Drives with a DNet adapter.
Power Flex Native Consumed Assembly
Instance 170 is the Power Flex Native Format Consumed Assembly
Table C.32 Instance 170 — Power Flex Native Format Consumed Assembly.
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0
At
Reference
140M On
Net Ctl
Status
Ready
Running
Rev
Running
Fwd
Alarm Tripped
1
Reserved
Contactor 1
➊
User In 5 User In 4 User In 3 User In 2 User In 1 User In 0
2 Output Frequency (Low) (xxx.x Hz)
3 Output Frequency (High) (xxx.x Hz)
4 Net Out 8 Net Out 7 Net Out 6 Net Out 5 Net Out 4 Net Out 3 Net Out 2 Net Out 1
5 Net Out 15
Net Out
14
Net Out
13
Net Out
12
Net Out
11
Net Out
10
Net Out 9
6 ZIP Device Value Key (Low)
7 ZIP Device Value Key (High)
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 MOP Inc reserved Direction Cmd Flt Reset Jog Start Stop
1 MOP Dec
Freq Select
3
Freq Select
2
Freq
Select 1
Decel
2
Decel
1
Accel
2
Accel
1
2 Comm Frequency Command (Low)
3 Comm Frequency Command (High)
