Installation and Wiring 2-13
Wiring Power, Control, and Ground Wiring
Table 2.1 provides the power, control, safety inputs, and ground wire
capacities, and the tightening torque requirements. The power,
control, ground, and safety monitor terminals will accept a maximum
of two wires per terminal.
Table 2.1 Power, Control, Safety Input, Ground Wire Size, and Torque
Specifications
Terminals Wire Size Torque Wire Strip Length
Power
and
Ground
Primary/Secondary
Terminal:
1.5…4.0 mm
2
(#16 …#10 AWG)
Primary Terminal:
10.8 lb.-in.
(1.2 N•m)
Secondary Terminal:
4.5 lb.-in
(0.5 N•m)
0.35 in. (9 mm)
Control and Safety
Inputs
1.0 mm
2
…4.0 mm
2
(#18…#10 AWG)
6.2 lb.-in
(0.7 N•m)
0.35 in. (9 mm)
