Bulletin 280G/281G CIP Information B-25
DeviceNet Interface Object -CLASS
CODE 0x00B4
This “vendor specific” object has no class attributes.
A single instance (instance 1) of the DeviceNet Interface Object is
supported:
Table B.58 DeviceNet Interface Object Instance Attribute
The following common services are implemented for the DeviceNet
Interface Object:
Table B.59 DeviceNet Interface Object Common Services
Attribute ID Access Rule Name Data Type Min/Max Default Description
7 Get/Set Prod Assy Word 0 USINT 0…108 1 Defines Word 0 of Assy 120
8 Get/Set Prod Assy Word 1 USINT 0…108 5 Defines Word 1 of Assy 120
9 Get/Set Prod Assy Word 2 USINT 0…108 6 Defines Word 2 of Assy 120
10 Get/Set Prod Assy Word 3 USINT 0…108 7 Defines Word 3 of Assy 120
13 Get/Set Starter COS Mask WORD 0…0xFFFF 0xFFFF Change of state mask for starter bits
15 Get/Set Autobaud Enable BOOL 0…1 1 1= enabled; 0 = disabled
16 Get/Set Consumed Assy USINT 0…185 160 3, 121, 160, 162, 182, 187
17 Get/Set Produced Assy USINT 100…187 161 52, 121, 161, 163, 181-187,189,190
19 Get/Set Set To Defaults BOOL 0…1 0 0=No action; 1=Reset
23 Get I/O Produced Size USINT 0…8 — Size of I/O Produced Data in Bytes
24 Get I/O Consumed Size USINT 0…3 — Size of I/O Consumed Data in Bytes
30 Get DNet Voltage UINT xx.xx — DeviceNet Voltage xx.xx Volts
50 Get/Set PNB COS Mask WORD 0 to 0x00FF 0 Change of state mask for PNBs
Service Code
Implemented for:
Service Name
Class Instance
0x0E No Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
