Roland FA-06 Parameter Guide

EFFECTS EDIT
16
Parameter Value Explanation
Comp+EQ Output tab
* This is shown only if the tone of the part specied by Drum Comp+EQ Assign is PCMD or SN-D.
Comp+EQ 1 Output Assign
PART, SUB
Specify the output destination for each the six drum kit compressor + equalizer units.
PART: Input to the MFX of the part.
SUB: Output in stereo to the SUB OUTPUT jack.
Comp+EQ 2 Output Assign
Comp+EQ 3 Output Assign
Comp+EQ 4 Output Assign
Comp+EQ 5 Output Assign
Comp+EQ 6 Output Assign
Master Comp tab
* This is shown only if M.COMP/IFX Select is set to “Master Comp.”
M.Comp Sw
([2] (M.Comp Sw) button)
OFF, ON Switches the master compressor on/o.
Low band Attack time 0–100
Low band
Time from when the input exceeds the Threshold until compression begins
Low band Release time 0–100
Time from when the input falls below the Threshold until compression is
removed
Low band Threshold -36–0 dB Level at which compression is applied
Low band Ratio 1:1.0–1:INF Compression ratio
Low band Level 0–24 dB Level of the output sound
Mid band Attack time 0–100
Middle band
Time from when the input exceeds the Threshold until compression begins
Mid band Release time 0–100
Time from when the input falls below the Threshold until compression is
removed
Mid band Threshold -36–0 dB Level at which compression is applied
Mid band Ratio 1:1.0–1:INF Compression ratio
Mid band Level 0–24 dB Level of the output sound
High band Attack time 0–100
High band
Time from when the input exceeds the Threshold until compression begins
High band Release time 0–100
Time from when the input falls below the Threshold until compression is
removed
High band Threshold -36–0 dB Level at which compression is applied
High band Ratio 1:1.0–1:INF Compression ratio
High band Level 0–24 dB Level of the output sound
Split Freq Low 200–800 Hz Frequency at which the low and mid bands are divided
Split Freq High 2000–8000 Hz Frequency at which the mid and high bands are divided
IFX tab
* This is shown only if M.COMP/IFX Select is set to “IFX.”
IFX Sw
([2] (IFX Sw) button)
OFF, ON Switches the insert eect on/o.
IFX Type 00–78
Use this parameter to select from among the 78 available insert eect. For details on insert eect
parameters, refer to “IFX Parameters” (p. 69).
IFX Chorus Send Level 0–127
Adjusts the amount of chorus.
If you don’t want to add the chorus eect, set it to 0.
IFX Reverb Send Level 0–127
Adjusts the amount of reverb.
If you don’t want to add the reverb eect, set it to 0.
IFX Output Assign MAIN, SUB
Species the output destination of the sound that passes through the insert eect.
The sound is output in stereo from the MAIN OUTPUT jacks, or from the SUB OUTPUT jack.
Parameters for each IFX type Edit the parameters for the selected IFX type.

Roland FA-06 Specifications

General

Control type	Buttons
Backlight color	Red
Backlight buttons	Yes
MIDI-keyboard number of keys	61 keys
Display type	LCD
Display diagonal	5 \
Product color	Black
Sound effects	Acoustic resonance, Synthesizer
Interface	USB
Headphone outputs	1
USB ports quantity	2
Compatible memory cards	SDHC
6.35 mm (1⁄4-inch) output	3
Power source type	AC
Bit rate	16 bit
Product type	Digital synthesizer
Keyboard number of keys	61
Maximum polyphony (notes)	128
Reverberation effects quantity	6

Weight and Dimensions

Depth	300 mm
Width	1008 mm
Height	101 mm
Weight	5700 g
