PCM Drum Kit (PCMD)
66
Parameter Value Explanation
Level V-Sens -63–+63
Set this when you want the volume of the drum partial to change depending on the force with
which you press the keys. Set this to a positive (+) value to have the changes in drum partial
volume increase the more forcefully the keys are played; to make the tone play more softly as you
play harder, set this to a negative (-) value.
Partial Pan L64–63R
Sets the pan for the drum partial. “L64” is far left, “0” is center, and “63R” is far right.
MEMO
Set the Pan for Waves comprising the drum partials with the Wave Pan parameter (p. 62).
Random Pan Depth 0–63
Use this parameter when you want the stereo location to change randomly each time you press a
key. Higher settings will produce a greater amount of change.
NOTE
This will aect only waves whose Wave Random Pan Sw parameter (p. 62) is ON.
Alternate Pan Depth L63–63R
This setting causes panning to be alternated between left and right each time a key is pressed.
Higher settings will produce a greater amount of change. “L” or “R” settings will reverse the order
in which the pan will alternate between left and right. For example if two drum partials are set to
“L” and “R” respectively, the panning of the two drum partials will alternate each time they are
played.
NOTE
This will aect only waves whose Wave Alter Pan Sw parameter (p. 62) is ON or REVS.
Relative Level -64–+63
Corrects for the volume of the drum partial.
This parameter is set by the key-based controller system exclusive message. Normally, you should
leave it set to 0.
NOTE
If the drum partial level is set to 127, the volume will not increase beyond that point.
TVA Env tab
TVA Env T1 V-Sens -63–+63
This allows keyboard dynamics to aect the Time 1 of the TVA envelope. If you want Time 1 to be
speeded up for strongly played notes, set this parameter to a positive (+) value. If you want it to be
slowed down, set this to a negative (-) value.
TVA Env T4 V-Sens -63–+63
The parameter to use when you want key release speed to control the Time 4 value of the TVA
envelope. If you want Time 4 to be speeded up for quickly released notes, set this parameter to a
positive (+) value. If you want it to be slowed down, set this to a negative (-) value.
TVA Env Time 1–4 0–127
Specify the TVA envelope times (Time 1–Time 4). Higher settings will lengthen the time until the
next volume level is reached (For example, Time 2 is the time over which Level 1 will change to
Level 2.).
TVA Env Level 1–3 0–127
Specify the TVA envelope levels (Level 1–Level 3). These settings specify how the volume will
change at each point, relative to the standard volume (the Partial Level value specied in the TVA
screen).
T1 T2 T3 T4
L3
L1
L2
Note o
Level
Time
Note on
T: Time L: Level
Output tab
Partial Output Assign PART, COMP+EQ1–6 Species how the sound of each partial will be output.
Partial Output Level 0–127 Species the signal level of each partial.
Partial Chorus Send Level 0–127 Species the level of the signal sent to the chorus for each partial.
Partial Reverb Send Level 0–127 Species the level of the signal sent to the reverb for each partial.
Comp tab
* COMP+EQ can be used only for the part specied by Drum Comp+EQ Assign.
Comp 1–6 Switch OFF, ON Compressor on/o
Comp 1–6 Attack Time 0.05–50.0 ms Time from when the input exceeds the threshold until compression begins
Comp 1–6 Release Time 0.05–2000 ms Time from when the input falls below the threshold until compression is turned o
Comp 1–6 Threshold 0–127 Level above which compression is applied
Comp 1–6 Ratio 1:1–inf:1 Compression ratio
Comp 1–6 Output Gain 0–+24 dB Level of the output sound
To Next Page
