5
Studio Set
STUDIO SET COMMON
1. Press the [MENU] button.
2. Move the cursor to “Studio Set Common” and press the [ENTER] button.
The STUDIO SET COMMON screen appears.
Parameter Value Explanation
General tab
Keyboard Mode
This species the play mode.
SINGLE Single play
SPLIT Split play
DUAL Dual play
STUDIO SET Multi part play
Pad Part Select Part1–Part16, OFF Species the pad part (the part that records performance data from the pads).
Drum Comp+EQ Assign Part1–Part16
Species the part that will use the six sets of compressor + equalizer that are provided for use with
a drum kit.
* If a tone (not a drum kit) is assigned to the part specied by Drum Comp+EQ Assign, the
Comp+EQ will not be available.
Control tab
Control Source Select (System) SYSTEM, STUDIO SET
SYSTEM: The Control Source Select system parameters System Control 1–4 Source are used for
tone control.
STUDIO SET: Tone Control Src1–4 are used for tone control.
* Control Source Select (System) settings are system parameters.
* If you choose “SYSTEM,” the settings of the studio set parameters Tone Control Src1–4 are
ignored.
Tone Control Src1–4
OFF,
CC01–CC31,
CC33–CC95,
PICTH BEND, AFTERTOUCH
Specify the MIDI messages that will be used for Tone Control of the studio set.
Phase Lock tab
Phase Lock (Ch1)–Phase Lock
(Ch16)
OFF, ON
Set Phase Lock to “ON” when you want to suppress discrepancies in timing of parts played on the
same MIDI channel.
When the Phase Lock parameter is set to “ON,” parts on the same MIDI channel are put in
a condition in which their timing is matched, enabling them to be played at the same time.
Accordingly, a certain amount of time may elapse between reception of the Note messages and
playing of the sounds. Turn this setting to “ON” only as needed.
* Phase Lock is not available for SuperNATURAL acoustic organ-type instruments.
To Next Page
