PCM Synth Tone (PCMS)
53
Parameter Value Explanation
TVF Env Time KF -100–+100
Use this setting if you want the TVF envelope times (Time 2–Time 4) to be aected by the keyboard
location. Based on the TVF envelope times for the C4 key (center C), positive (+) value will cause
notes higher than C4 to have increasingly shorter times, and negative (-) value will cause them to
have increasingly longer times. Larger settings will produce greater change.
C4C3C2C1 C5 C6 C7
0
+50
+100
-50
-100
Key
Time
TVF Env Time 1–4
0–127
Specify the TVF envelope times (Time 1–Time 4). Higher settings will lengthen the time until the
next cuto frequency level is reached (For example, Time 2 is the time over which Level 1 will
change to Level 2.).
* You can control this parameter using the Matrix Control.
T1 T2 T3 T4
L3
L1
L0
L2 L4
Note o
Cuto
Frequency
Time
Note on
T: Time L: Level
TVF Env Level 0-4 0–127
Specify the TVF envelope levels (Level 0–Level 4). These settings specify how the cuto frequency
will change at each point, relative to the standard cuto frequency (the cuto frequency value
specied in the TVF screen).
TVA tab
Partial Level
0–127
Sets the volume of the partial. This setting is useful primarily for adjusting the volume balance
between partials.
* You can control this parameter using the Matrix Control.
Level V-Curve FIXED, 1–7
Selects one of the following seven curves that determine how keyboard dynamics will aect
the volume. Set this to “FIXED” if you don’t want the volume of the partial to be aected by the
keyboard velocity.
1 2 3 4 5 6 7
Level V-Sens -63–+63
Set this when you want the volume of the partial to change depending on the force with which
you press the keys. Set this to a positive (+) value to have the changes in partial volume increase
the more forcefully the keys are played; to make the partial play more softly as you play harder, set
this to a negative (-) value.
MEMO
If you wish to make adjustments to the entire tone while maintaining the relative values of
TVA Level V-Sens among partials, adjust the Velocity Sens Oset parameter (p. 43). However, this
setting is shared by the Cuto V-Sens parameter (p. 52).
Bias Level -100–+100
Adjusts the angle of the volume change that will occur in the selected Bias Direction. Larger
settings will produce greater change.
Negative (-) values will invert the change direction.
Bias Position C-1–G9 Species the key relative to which the volume will be modied.
Bias Direction
Selects the direction in which change will occur starting from the Bias Position.
LWR The volume will be modied for the keyboard area below the Bias Point.
UPR The volume will be modied for the keyboard area above the Bias Point.
L&U The volume will be modied symmetrically toward the left and right of the Bias Point.
ALL The volume changes linearly with the bias point at the center.
