Remote
Remote
Remote functions
You can use the rear panel MIDI IN/OUT connectors to remotely
control the M-200i from an external device, or control an external
device from the M-200i. You can use either MIDI or RS-232C, not
both.
In order to use MIDI, go to the REMOTE screen and set “RS-232C/
MIDI SELECT“ to MIDI.
MIDI can transmit and receive the following messages:
By connecting the rear panel USB port to a PC, you can use USB
MIDI to remotely control the M-200i.
USB MIDI can transmit and receive the following messages:
You’ll need to install the USB MIDI driver on the PC that’s to be
connected to the M-200i using USB. Download the USB MIDI
driver from the Roland website below:
http://www.rolandsystemsgroup.net/
The M-200i can be remotely controlled from M-200iRCS via its
rear panel USB connector. M-200iRCS is application software
that runs on Windows PC or Mac. It allows you to edit M-200i
project files and to remotely control the M-200i. You can obtain
the “M-200iRCS” software and the “M-200iRCS Users Guide”
(PDF version) from the Roland website listed below. For details
on using M-200iRCS, refer to the “M-200iRCS Users Guide.”
http://www.rolandsystemsgroup.net/
You can use the RS-232C connector located on the rear panel to
control the M-200i from an external computer or other device.
For details on the RS-232C commands, refer to the “M-200i RS-
232C Reference” (PDF version), which you can obtain from the
Roland website listed below:
http://www.rolandsystemsgroup.net/
To use RS-232C, go to the REMOTE screen and set “RS-232C/
MIDI SELECT“ to RS-232C.
If you connect a V-LINK compatible video device such as the V-
1600HD to the rear panel MIDI IN connector, you’ll be able to use
your video device to control the volume of specific channels.
The M-200i allows up to 16 audio sources to be controlled via
VLINK.
The following V-LINK compatible video devices can be connected
to the M-200i:
• V-440HD (Ver. 2.07 or later)
• V-8
• LVS-800
• V-1600HD
• V-800HD
In order to use V-LINK, go to the REMOTE screen and set “RS-
232C/MIDI SELECT“ to MIDI.
The M-200i can use MIDI and USB MIDI simultaneously. If the
same message is received via both MIDI and USB MIDI, the last-
received message will be used.
MIDI
Message
Explanation Transmitted/
Received
Control change
Control of channel faders and
mute
Transmitted/
Received
Program change Recall scene memories Transmitted/
Received
System exclusive Control of mixer parameters Transmitted/
Received
MMC Control of the USB memory
recorder
Received only
USB MIDI
Message
Explanation Transmitted/
Received
Control change
Control of channel faders and
mute
Transmitted/
Received
Program change Recall scene memories Transmitted/
Received
System exclusive Control of mixer parameters Transmitted/
Received
MMC Control of the USB memory
recorder
Received only
RS-232C
V-LINK
