25
Explanation of the panels
Explanation of the panels
Connecting an iPad to the unit using the included dock cable lets
you control the unit remotely from the iPad.
Charging starts automatically when an iPad is connected.
This slot contains a lithium battery that maintains the M-200i's
clock function and preserves the mixer settings.
If the battery runs down, you need to replace it. For details on
replacing the battery, refer to“About the internal lithium battery”
(p. 16).
You can use this power cord hook to prevent the power cord
from being accidentally disconnected.
For details on attaching the power cord hook, refer to
“Attaching the power cord hook” (p. 14).
Unsuitable places for connection.
Do not ground the M-200i to locations such as the following:
• Water pipes (may result in shock or electrocution)
• Gas pipes (may result in fire or explosion)
• Telephone-line ground or lightning rod (may be dangerous
in the event of lightning)
Depending on the circumstances of a particular setup, you
may experience a discomforting sensation, or perceive that
the surface feels gritty to the touch when you touch this
device, microphones connected to it, or the metal portions
of other objects, such as guitars. This is due to an
infinitesimal electrical charge, which is absolutely harmless.
However, if you are concerned about this, connect the
ground terminal (see figure) with an external ground. When
the unit is grounded, a slight hum may occur, depending on
the particulars of your installation. If you are unsure of the
connection method, contact the nearest Roland Service
Center, or an authorized Roland distributor, as listed on the
“Information” leaflet.
Use this to supply power from a connected AC adapter (PSB-14U).
Never connect any power cord to the M-200i other than the
included one.
This turns the power on and off.
“Turning the power on/off” (p. 15)
DOCK CABLE connector
BATTERY slot
Power cord hook
Grounding terminal
13
14
15
16
AC adapter connector
POWER Switch
M-200i_e.book 25 ページ ２０１３年１月１６日 水曜日 午後４時９分
