67
Effects,GEQ,External effects
Effects,GEQ,External effects
Effects such as reverb and delay are typically used in a send/
return configuration.
Here we will explain the procedure for using FX3 as a send/return
type effect using AUX7, CH25 and CH26.
1.
Access the EFFECTS FUNCTION screen.
2.
Move the cursor to the FX 3 SOURCE, and press [ENTER].
The FX 3 SOURCE screen will appear.
3.
Move the cursor to the AUX7 OUT, and press [ENTER] to
select it.
4.
In the same way as you did in steps 1 through 3, select
AUX7 as the input-source for the R side of FX3.
1.
Access the EFFECTS FUNCTION screen.
2.
Move the cursor to the FX3 L DESTINATION, and press
[ENTER].
The FX3 DESTINATION screen will appear.
3.
Move the cursor to the CH25, and press [ENTER] to select
it.
If an input port is already patched to the channel, a message
will ask you to confirm the input patching change.
Press [ENTER] to change the input patching.
If the “PATCHBAY CHANGE” item in the CONFIRMATION section
of User Preference (p. 94) is not in effect, no confirmation
message will appear in step 3.
4.
In the same way as you did in steps 1 through 4, select
CH26 as the output-destination for the R side of FX3.
Using an effect via send/return
Specifying the effect input-source
Specifying the effect return channel
