13
Introduction
Introduction
Placement
It is possible to adjust the angle of the iPad with the included
iPad stand.
When the M-200i is shipped from the factory, a REAC cap is
attached to the REAC port. In order to use REAC port, you’ll need
to remove the REAC cap. Take care not to lose the REAC caps you
remove.
fig.connection.eps
Depending on the circumstances of a particular setup, you may
experience a discomforting sensation, or perceive that the
surface feels gritty to the touch when you touch this device,
microphones connected to it, or the metal portions of other
objects, such as guitars. This is due to an infinitesimal electrical
charge, which is absolutely harmless. However, if you are
concerned about this, connect the ground terminal (see figure)
with an external ground. When the unit is grounded, a slight hum
may occur, depending on the particulars of your installation. If
you are unsure of the connection method, contact the nearest
Roland Service Center, or an authorized Roland distributor, as
listed on the Information leaflet.
Unsuitable places for connection
• Water pipes (may result in shock or electrocution)
• Gas pipes (may result in fire or explosion)
• Telephone-line ground or lightning rod (may be dangerous
in the event of lightning)
Place the AC adaptor so the side with the indicator (see
illustration) faces upwards and the side with textual information
faces downwards.
The indicator will light when you plug the AC adaptor into an AC
outlet.
How to Use TABLET STAND
About the REAC caps
AC power connections
Indicator
AC Outlet
Power Cord
AC Adaptor
