62
Mute groups
Mute groups
Mute grouping is a function that lets you control the mute status
of multiple channels belonging to a mute group.
A channel can belong to more than one mute group.
You use the MUTE GROUP screen to make mute group settings.
1.
In the DISPLAY section, press [MUTE].
The MUTE GROUP screen is displayed.
MUTE buttons
These buttons turn on/off muting of multiple channels
assigned to the respective mute groups.
MUTE ALL OUT button
This mutes the all output for the M-200i and any input and
output units.
You can also configure USER buttons to turn mute groups on
and off (p. 95).
Output muting controlled by MUTE ALL OUT cannot be stored
in a scene memory. When the M-200i starts, muting by MUTE
ALL OUT is off.
1.
Access the MUTE GROUP screen.
2.
Press [FUNC] to access the MUTE GROUP FUNCTION
screen.
The operations available from the MUTE GROUP FUNCTION
screen are as follows:
Selecting “GROUP ASSIGN“ at the CHANNEL EDIT FUNCTION
screen also lets you assign channels to mute groups. For details,
refer to “Assigning channels to DCA groups and mute groups”
(p. 38).
1.
Access the MUTE GROUP FUNCTION screen.
2.
Select one from among “MUTE1-8 ASSIGN“ and press
[ENTER] to access the MUTE ASSIGN screen.
3.
Select the desired channel and press [ENTER].
4.
Press [EXIT] to quit the screen.
Pressing [SEL] at the top panel while the MUTE ASSIGN screen is
displayed lets you turn the corresponding channel's assignment
to the mute group on/off.
About mute groups
Accessing the MUTE GROUP screen
1
2
MUTE GROUP FUNCTION screen
MUTE 1-4 ASSIGN
These buttons access the MUTE GROUP
ASSIGN screen (p. 62)
MUTE 1-4 NAME EDIT These buttons access the NAME EDIT screen
(p. 63)
Assigning a channel to a mute group
M-200i_e.book 62 ページ ２０１３年１月１６日 水曜日 午後４時９分
