P
ORT
C
ONFIGURATION
3-127
Displaying LACP Settings and Status for the Remote Side
You can display configuration settings and the operational state for the
remote side of an link aggregation.
Neighbor Configuration Information
Table 3-10. LACP Remote Side Settings
Field Description
Partner Admin System
ID
LAG partner’s system ID assigned by the user.
Partner Oper System
ID
LAG partner’s system ID assigned by the LACP
protocol.
Partner Admin
Port Number
Current administrative value of the port number for the
protocol Partner.
Partner Oper
Port Number
Operational port number assigned to this aggregation
port by the port’s protocol partner.
Port Admin Priority Current administrative value of the port priority for the
protocol partner.
Port Oper Priority Priority value assigned to this aggregation port by the
partner.
Admin Key Current administrative value of the Key for the protocol
partner.
Oper Key Current operational value of the Key for the protocol
partner.
Admin State Administrative values of the partner’s state parameters.
(See preceding table.)
Oper State Operational values of the partner’s state parameters.
(See preceding table.)
