SMC Networks TigerSwitch SMC6128L2 User Manual

C OMMAND L INE I NTERFACE
4-120
• If a port is already bound to an ACL and you bind it to a different
ACL, the switch will replace the old binding with the new one.
• You must configure a mask for an ACL rule before you can bind it to
a port.
Example
Related Commands
show ip access-list (4-118)
show ip access-group
This command shows the ports assigned to IP ACLs.
Command Mode
Privileged Exec
Example
Related Commands
ip access-group (4-119)
map access-list ip
This command sets the output queue for packets matching an ACL rule.
The specified CoS value is only used to map the matching packet to an
output queue; it is not written to the packet itself. Use the no form to
remove the CoS mapping.
Syntax
[no] map access-list ip acl_name cos cos-value
• acl_name – Name of the ACL. (Maximum length: 16 characters)
• cos-value – CoS value. (Range: 0-7)
Console(config)#int eth 1/25
Console(config-if)#ip access-group standard david in
Console(config-if)#
Console#show ip access-group
Interface ethernet 1/25
IP standard access-list david
Console#

SMC Networks TigerSwitch SMC6128L2 Specifications

General

Model	SMC6128L2
Port Speed	10/100/1000 Mbps
Switching Capacity	56 Gbps
MAC Address Table Size	8K
Jumbo Frame Support	Yes
Manageable	Yes
Power Supply	Internal
Power Consumption	30 W
Weight	2.5 kg
Type	Switch
Jumbo Frame Support Size	9216 bytes
Forwarding Rate	41.7 Mpps
