C
ONFIGURING
THE
S
WITCH
3-138
Web – Click Port, Port Statistics. Select the required interface, and click
Query. You can also use the Refresh button at the bottom of the page to
update the screen.
Figure 3-60. Displaying Port Statistics
Fragments The total number of frames received that were less
than 64 octets in length (excluding framing bits, but
including FCS octets) and had either an FCS or
alignment error.
64 Bytes Frames The total number of frames (including bad packets)
received and transmitted that were 64 octets in length
(excluding framing bits but including FCS octets).
65-127 Byte Frames
128-255 Byte Frames
256-511 Byte Frames
512-1023 Byte Frames
1024-1518 Byte Frames
1519-1536 Byte Frames
The total number of frames (including bad packets)
received and transmitted where the number of octets
fall within the specified range (excluding framing bits
but including FCS octets).
Table 3-11. Port Statistics (Continued)
Parameter Description
