B
ASIC
C
ONFIGURATION
3-29
Note: You can also select any configuration file as the start-up
configuration by using the System/File Management/Set Start-Up
page.
Figure 3-13. Setting the Startup Configuration Settings
CLI – Enter the IP address of the TFTP server, specify the source file on
the server, set the startup file name on the switch, and then restart the
switch.
To select another configuration file as the start-up configuration, use the
boot system command and then restart the switch.
Console Port Settings
You can access the onboard configuration program by attaching a VT100
compatible device to the switch’s serial console port. Management access
through the console port is controlled by various parameters, including a
password, timeouts, and basic communication settings. These parameters
can be configured via the web or CLI interface.
Console#copy tftp startup-config 4-84
TFTP server ip address: 192.168.1.19
Source configuration file name: config-1
Startup configuration file name [] : startup
\Write to FLASH Programming.
-Write to FLASH finish.
Success.
Console#reload
Console#config
Console(config)#boot system config: startup-new 4-90
Console(config)#exit
Console#reload 4-30
