B
ASIC
C
ONFIGURATION
3-17
CLI – Use the following command to display version information.
Displaying Bridge Extension Capabilities
The Bridge MIB includes extensions for managed devices that support
Multicast Filtering, Traffic Classes, and Virtual LANs. You can access these
extensions to display default settings for the key variables.
Field Attributes
• Extended Multicast Filtering Services – This switch does not
support the filtering of individual multicast addresses based on GMRP
(GARP Multicast Registration Protocol).
• Traffic Classes – This switch provides mapping of user priorities to
multiple traffic classes. (Refer to “Displaying Private VLAN Interface
Information” on page 3-181.)
• Static Entry Individual Port – This switch allows static filtering for
unicast and multicast addresses. (Refer to “Setting Static Addresses”
on page 3-140.)
• VLAN Learning – This switch uses Independent VLAN Learning
(IVL), where each port maintains its own filtering database.
Console#show version 4-81
Unit 1
Serial Number:
Hardware Version:
EPLD Version: 0.01
Number of Ports: 28
Main Power Status: Up
Redundant Power Status: Not present
Agent (Master)
Unit ID: 1
Loader Version: 1.0.0.0
Boot ROM Version: 1.0.0.3
Operation Code Version: 1.0.0.8
Console#
