VLAN C ONFIGURATION
3-175
Web – Click VLAN, 802.1Q VLAN, Port Configuration or Trunk
Configuration. Fill in the required settings for each interface, click Apply.
Figure 3-74. Configuring VLAN Ports
CLI – This example sets port 3 to accept only tagged frames, assigns
PVID 3 as the native VLAN ID, and then sets the switchport mode to
hybrid.
Console(config)#interface ethernet 1/3 4-144
Console(config-if)#switchport acceptable-frame-types tagged 4-200
Console(config-if)#switchport ingress-filtering 4-202
Console(config-if)#switchport native vlan 3 4-203
Console(config-if)#switchport gvrp 4-216
Console(config-if)#switchport mode hybrid 4-200
Console(config-if)#
