To configure primary/secondary associated groups, follow these steps:
1. Use the private-vlan command to designate one or more
community VLANs and the primary VLAN that will channel
traffic outside of the community groups.
2. Use the private-vlan association command to map the community
VLAN(s) to the primary VLAN.
3. Use the switchport mode private-vlan command to configure
ports as promiscuous (i.e., having access to all ports in the primary
VLAN) or host (i.e., community port).
4. Use the switchport private-vlan host-association command to
assign a port to a secondary VLAN.
5. Use the switchport private-vlan mapping command to assign a
port to a primary VLAN.
6. Use the show vlan private-vlan command to verify your
configuration settings.
Table 4-58 Private VLAN Commands
Command Function Mode Page
Edit Private VLAN Groups
private-vlan Adds or deletes primary or community
VLANs
VC 4-209
private-vlan association Associates a community VLAN with a
primary VLAN
VC 4-210
Configure Private VLAN Interfaces
switchport mode
private-vlan
Sets an interface to host mode or
promiscuous mode
IC
switchport private-vlan
host-association
Associates an interface with a
secondary VLAN
IC
switchport private-vlan
mapping
Maps an interface to a primary VLAN IC
Display Private VLAN Information
show vlan private-vlan Shows private VLAN information NE,
PE
