C
OMMAND
L
INE
I
NTERFACE
4-114
The following restrictions apply to ACLs:
• Each ACL can have up to 60 rules.
• This switch supports ACLs for ingress filtering only. However, you can
only bind one IP ACL to any port for ingress filtering. In other words,
only one ACL can be bound to an interface - Ingress IP ACL.
The order in which active ACLs are checked is as follows:
1. User-defined rules in the Ingress IP ACL for ingress ports.
2. Explicit default rule (permit any any) in the ingress IP ACL for ingress
ports.
3. If no explicit rule is matched, the implicit default is permit all.
IP ACLs
Table 4-33 Access Control List Commands
Command Groups Function Page
IP ACLs Configure ACLs based on IP addresses, TCP/
UDP port number, protocol type, and TCP control
code
4-114
ACL Information Display ACLs and associated rules; shows ACLs
assigned to each port
4-122
Table 4-34 IP ACL Commands
Command Function Mode Page
access-list ip Creates an IP ACL and enters
configuration mode for standard or
extended IP ACLs
GC 4-115
permit, deny Filters packets matching a specified
source IP address
STD-ACL 4-116
permit, deny Filters packets meeting the specified
criteria, including source and
destination IP address, TCP/UDP port
number, protocol type, and TCP
control code
EXT-ACL 4-117
