6-14
6-2. ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
• Abbreviation
CND : Canadian model
EE : East European model
NE : North European model
RU : Russian model
HK : Hong Kong model
AUS : Australian model
CN : Chinese model
BR : Brazilian model
JE : Tourist model
When indicating parts by reference number,
please include the board name.
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
A-7073-865-A CD-212 BOARD, COMPLETE
(TRV103/TRV110/TRV110P/TRV203/TRV210/
TRV310/TRV310P/TRV315/TR7000)
**********************
(Ref.No:10000 Series)
(IC1401 is not included in this complete board.)
< CAPACITOR >
C1402 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C1405 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1406 1-113-682-11 TANTAL. CHIP 33uF 20% 10V
C1407 1-107-820-11 CERAMIC CHIP 0.1uF 16V
< CONNECTOR >
CN1401 1-766-346-21 CONNECTOR, FFC/FPC 16P
< IC >
IC1401 A-7030-821-A CCD BLOCK ASSY (CCD IMAGER)
< COIL >
L1402 1-414-757-11 INDUCTOR 100uH
< TRANSISTOR >
Q1401 8-729-117-73 TRANSISTOR 2SC4178-F13F14-T1
< RESISTOR >
R1401 1-218-990-11 SHORT 0
R1402 1-218-990-11 SHORT 0
R1403 1-218-959-11 RES,CHIP 3.3K 5% 1/16W
************************************************************
A-7073-940-A CD-213 BOARD, COMPLETE
(TRV110E/TRV210E/TRV310E/TR7000E/TR7100E)
**********************
(Ref.No:10000 Series)
(IC2401 is not included in this complete board.)
< CAPACITOR >
C2401 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C2402 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C2406 1-113-682-11 TANTAL. CHIP 33uF 20% 10V
C2407 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C2408 1-135-177-21 TANTALUM CHIP 1uF 20% 20V
C2409 1-135-210-11 TANTALUM CHIP 4.7uF 20% 10V
C2411 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 16V
< CONNECTOR >
CN2401 1-766-346-21 CONNECTOR, FFC/FPC 16P
< IC >
IC2401 A-7030-855-A CCD BLOCK ASSY (CCD IMAGER)
IC2402 8-759-561-46 IC AD8014ART-REEL7
< COIL >
L2401 1-414-757-11 INDUCTOR 100uH
L2402 1-414-757-11 INDUCTOR 100uH
< RESISTOR >
R2401 1-218-940-11 RES,CHIP 82 5% 1/16W
R2402 1-218-990-11 SHORT 0
R2404 1-218-953-11 RES,CHIP 1K 5% 1/16W
R2405 1-218-961-11 RES,CHIP 4.7K 5% 1/16W
R2406 1-218-962-11 RES,CHIP 5.6K 5% 1/16W
************************************************************
A-7073-870-A CF-62(B) BOARD, COMPLETE
(TRV103/TRV110/TRV110E/TRV110P)
************************
(Ref.No.:7000 Series)
A-7073-921-A CF-65(C) BOARD, COMPLETE
(TR7000/TR7000E/TR7100E)
************************
(Ref.No.:9000 Series)
A-7073-926-A CF-63(C) BOARD, COMPLETE (TRV315)
************************
A-7073-955-A CF-63(B) BOARD, COMPLETE
(TRV203/TRV210/TRV210E/TRV310/TRV310E/TRV310P)
************************
(Ref.No.:8000 Series)
< BATTERY HOLDER >
BH001 1-550-104-11 HOLDER, BATTERY
< BUZZER >
BZ001 1-529-107-11 BUZZER, PIEZOELECTRIC
(TR7000/TR7000E/TR7100E)
Be sure to read “Precautions upon replacing CCD imager”
on page 4-11,14 when changing the CCD imager.
CD-212 CD-213 CF-62/63/65
