6-19
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R879 1-216-837-11 METAL CHIP 22K 5% 1/16W
R880 1-218-895-11 RES,CHIP 100K 0.50% 1/16W
R881 1-218-877-11 RES,CHIP 18K 0.50% 1/16W
R882 1-218-903-11 RES,CHIP 220K 0.50% 1/16W
R883 1-216-841-11 METAL CHIP 47K 5% 1/16W
(EXCEPT:TR7000/TR7000E/TR7100E)
R884 1-216-845-11 METAL CHIP 100K 5% 1/16W
(EXCEPT:TR7000/TR7000E/TR7100E)
R885 1-216-845-11 METAL CHIP 100K 5% 1/16W
(TRV315/TR7000/TR7000E/TR7100E)
R887 1-216-849-11 METAL CHIP 220K 5% 1/16W
(EXCEPT:TR7000/TR7000E/TR7100E)
R888 1-216-845-11 METAL CHIP 100K 5% 1/16W
(EXCEPT:TR7000/TR7000E/TR7100E)
R889 1-216-837-11 METAL CHIP 22K 5% 1/16W
(TRV315/TR7000/TR7000E/TR7100E)
R890 1-216-845-11 METAL CHIP 100K 5% 1/16W
R891 1-218-895-11 RES,CHIP 100K 0.50% 1/16W
(EXCEPT:TR7000/TR7000E/TR7100E)
R892 1-218-903-11 RES,CHIP 220K 0.50% 1/16W
(EXCEPT:TR7000/TR7000E/TR7100E)
R893 1-216-835-11 METAL CHIP 15K 5% 1/16W
(EXCEPT:TR7000/TR7000E/TR7100E)
R894 1-216-857-11 METAL CHIP 1M 5% 1/16W
(TRV315/TR7000/TR7000E/TR7100E)
R895 1-216-837-11 METAL CHIP 22K 5% 1/16W
R896 1-218-903-11 RES,CHIP 220K 0.50% 1/16W
(EXCEPT:TR7000/TR7000E/TR7100E)
R897 1-218-891-11 RES,CHIP 68K 0.50% 1/16W
(EXCEPT:TR7000/TR7000E/TR7100E)
R898 1-218-895-11 RES,CHIP 100K 0.50% 1/16W
(TRV315/TR7000/TR7000E/TR7100E)
R899 1-218-881-11 RES,CHIP 27K 0.50% 1/16W
(TRV315/TR7000/TR7000E/TR7100E)
R900 1-218-895-11 RES,CHIP 100K 0.50% 1/16W
R901 1-218-887-11 RES,CHIP 47K 0.50% 1/16W
R902 1-218-875-11 RES,CHIP 15K 0.50% 1/16W
R903 1-216-845-11 METAL CHIP 100K 5% 1/16W
(EXCEPT:TR7000/TR7000E/TR7100E)
R904 1-216-849-11 METAL CHIP 220K 5% 1/16W
(EXCEPT:TR7000/TR7000E/TR7100E)
R905 1-218-901-11 RES,CHIP 180K 0.50% 1/16W
(EXCEPT:TR7000/TR7000E/TR7100E)
R906 1-216-833-11 METAL CHIP 10K 5% 1/16W
(EXCEPT:TR7000/TR7000E/TR7100E)
R907 1-218-903-11 RES,CHIP 220K 0.50% 1/16W
(EXCEPT:TR7000/TR7000E/TR7100E)
R908 1-216-841-11 METAL CHIP 47K 5% 1/16W
R910 1-216-833-11 METAL CHIP 10K 5% 1/16W
R911 1-218-883-11 RES,CHIP 33K 0.50% 1/16W
R912 1-218-879-11 RES,CHIP 22K 0.50% 1/16W
R913 1-216-857-11 METAL CHIP 1M 5% 1/16W
R914 1-216-811-11 METAL CHIP 150 5% 1/16W
(EXCEPT:TR7000/TR7000E/TR7100E)
R915 1-218-911-11 RES,CHIP 470K 0.50% 1/16W
(EXCEPT:TR7000/TR7000E/TR7100E)
R916 1-216-864-11 METAL CHIP 0 5% 1/16W
(TRV315/TR7000/TR7000E/TR7100E)
R917 1-216-864-11 METAL CHIP 0 5% 1/16W
(EXCEPT:TRV315/TR7000/TR7000E/TR7100E)
R918 1-216-849-11 METAL CHIP 220K 5% 1/16W
(EXCEPT:TR7000/TR7000E/TR7100E)
R921 1-216-296-91 SHORT 0
R922 1-216-296-91 SHORT 0
R923 1-216-296-91 SHORT 0
R924 1-216-849-11 METAL CHIP 220K 5% 1/16W
(EXCEPT:TR7000/TR7000E/TR7100E)
R925 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
(EXCEPT:TR7000/TR7000E/TR7100E)
R926 1-216-821-11 METAL CHIP 1K 5% 1/16W
R932 1-216-841-11 METAL CHIP 47K 5% 1/16W
R933 1-216-821-11 METAL CHIP 1K 5% 1/16W
R934 1-216-821-11 METAL CHIP 1K 5% 1/16W
R935 1-216-821-11 METAL CHIP 1K 5% 1/16W
R936 1-216-821-11 METAL CHIP 1K 5% 1/16W
R937 1-216-821-11 METAL CHIP 1K 5% 1/16W
R938 1-216-821-11 METAL CHIP 1K 5% 1/16W
R939 1-216-821-11 METAL CHIP 1K 5% 1/16W
R940 1-216-819-11 METAL CHIP 680 5% 1/16W
R941 1-216-821-11 METAL CHIP 1K 5% 1/16W
R942 1-216-821-11 METAL CHIP 1K 5% 1/16W
R943 1-216-029-00 METAL CHIP 150 5% 1/10W
R945 1-217-671-11 METAL CHIP 1 5% 1/10W
< TRANSFORMER >
! T801 1-429-565-21 TRANSFORMER, CONVERTER
(EXCEPT:TR7000/TR7000E/TR7100E)
! T801 1-431-749-11 TRANSFORMER, DC/DC CONVERTER
(TR7000/TR7000E/TR7100E)
************************************************************
FP-249 BOARD, COMPLETE (Not supplied)
**********************
(Ref.No.:20000 Series)
1-658-214-11 FP-356 FLEXIBLE BOARD
3-965-551-01 HOLDER (S), SENSOR
3-965-552-01 HOLDER (T), SENSOR
< HOLE ELEMENT >
H001 8-719-033-37 ELEMENT, HALL HW-105C
H002 8-719-033-37 ELEMENT, HALL HW-105C
< TRANSISTOR >
Q001 8-729-907-25 PHOTO TRANSISTOR PT4850F
Q002 8-729-907-25 PHOTO TRANSISTOR PT4850F
< SWITCH >
S001 1-692-614-11 SWITCH, PUSH (3 KEY)
(Hi8 MP,ME/MP,REC PROOF)
S002 1-572-688-11 SWITCH, PUSH (1 KEY)(C.C.LOCK)
************************************************************
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
DD-117 FP-249
