2-8
VC-213
1 Harness guide
Claws
Claws
Claws
3 VF base (C) (95)
5 Slide fixed base (C)
6 Two screws (M2 × 3)
lock ace, p2
8 Remove the claw
!º Slide base (C) (95)
assembly
9 FP-47 flexible board
!¶ FP-47 flexible
board
!¡
!£ Two tapping
screws (B2
× 5)
!∞ Two tapping
screws (B2
× 5)
!¢ EVF cabinet
(rear C) (95)
!• EVF cabinet
(lower C) (95)
!ª
@º
Claws
@™ Claws
@£ Board holder
@¡ VF-126 board
VF-126 board
VF-126 board
@¢ VF-126 board
@∞
!§
EVF cabinet (upper C) (95)
4 Remove the slide fixed base (C)
by sliding it in the arrow direction
7 Remove the harness
retainer from FP-47
flexible board
2 Screw (M2 × 3)
lock ace, p2
FP-47 flexible board
[COLOR EVF CHECK SERVICE POSITION]
AC POWER
ADAPTOR
FP-77 flexible board (22P)
Cabinet (R) assembly
AC IN
LANC jack
DC IN
Adjustment remote
commander (RM-95)
CPC-13 jig
(J-6082-443-A)
CPC-13 jig
FFC-236 flexible
flat cable (50P)
Panel (N) (front) assembly
VF lens assembly
!™ Turn the lever
in the direction
of the arrow.
DP-75 harness (10P)
Note: the TR models do not have
the harness (DP-75)
Insulater
side
2-8. VF-126 BOARD (COLOR EVF MODEL)
